Description
Weights and measures
Inside Size (LxWxH) 415x175x35 cm
Total size (LxWxH) 544x180x103 cm
Loading height 69 cm
Total Weight 2.000 kg
Tare/Payload 500kg/1,500 kg
Structure
Wheel 4 PCs, 13 "
Axles 2 PCs, with brake
Side Material Aluminum
Bottom Finish, 15 mm
Standard Equipment
Retractable Heavy Duty Jockey Wheel – Yes
13 Or 7 pin plugs Yes
Inside lashing Supplies 10 PCs.
Retractable/removable sides Yes, all 4
Removable corner posts Yes
Optional Extras Available With This Model
Flat Tarpaulin Yes
Extra Alusides open up., 35 cm Yes
High pressure/stand, inside 145 cm Yes
High pressure/stand, inside 210 cm Yes
Net grid, 60 cm Yes
Aluminum Bottom Yes
Front Stand Yes
LED Light kit incl. control box Yes
Shock absorbers (excl. Approved) Yes
Dispensers under the ladder Yes
Our chassis frames are hot dipped galvanised and with high demands on quality, safety and reliability – that's why we develop the very strongest and sturdiest trailers you will find imported from Europe.
New E4 rated Tubeless radials on all wheels.
Using either Knott/Al-ko rubber torsion suspension system or axle leaf spring systems for greater road stability.
With safety white reflectors to the front, amber reflectors to the side and red to the rear as standard.
Bright White safety reversal light.
Whether It's a 2000kg, 2700kg or 3500kg knott/Al-ko, all couplings have a lockable position for greater security.
Our Knott Braking system is of the mechanical overrun type – the hydraulically dampened overrun control device includes drum braking to all wheels, a dedicated handbrake and auto reverse mechanism.
TUV load securing system with lashing brackets integrated into the side edges.
Removable corner posts.
Unique Easy Attachment panel hinges.
Heavy profiled aluminum Front, rear and side panels with integrated fasteners.
When Choosing your trailer, you will see that our tare weights are lower meaning greater payloads and overall reduced fuel consumption.
Our trailers are designed to get the job done in the right situation.
We deliver to businesses, government and private individuals, who want to work with the strongest trailers.
Extra weather treatments can be added to your trailer to increase protection against atmosphere and increase weather repellence.
We have developed the strongest and most robust trailers in Europe.
Always with the user in mind; demanding companies and private individuals. We do not settle for average quality, we strive for perfection. Our trailers are designed to get the job done. Whatever the challenge may be, we will meet it.
